DCDC-omvandlare 24V till 12V 3A
364,70 SEK/styck
- Betala säkert med kort, Klarna Checkout eller egen faktura.
- Maila oss, vi svarar snabbt!
Beskrivning
Art.nr: 241230
Artikelnr. 241230
| Input | 12 / 19 / 24V DC |
| Input voltage range | 5-32V DC |
| Efficiency | 93%(half load), 91%(full load) |
| Output Voltage | 12V |
| Output current | 1A /2A / 3A |
| Output rated power | 12W / 24W / 36W Max |
| Output peak power | 15W / 30W / 43W |
| Voltage regulation | < 1% |
| Load regulation | < 2% |
| Working temperature | -40°C~80°C (If ambient temperature exeeds 40°C, lower power use, or to enhance heat dissipation) |
| Module Properties | non-isolated module |
| Rectification | synchronous rectification |
| Waterproof rating | IP68 |
| Full load temperature rice: | 50°C |
| Protection | Over-current, Over-temperature, Instant absorption of high voltage prot waterprof IP68, anti-shook protection |
| Short-circuit protection | NO, if needed pls add fuse on the positive pole on input |
| Input Reverse Polarity protection | None (Plaese Series diode at the inputport.) |
| NW | ABS: 65G |
| Size | 46x32x18mm |
